African Metal Suppliers is manufacturers, stockiest & suppliers of super duplex uns s32760 Pipe. super duplex uns s32760 Pipe have special quality finishing and duress for long life, high pressure and zero defects.African Metal Suppliers supplies super duplex uns s32760 Pipe to internationally approved quality standards for applications.As well as being available from stock all super duplex uns s32760 Pipe can be cut to size and shape according to your fabrication and design requirements and all work is governed by our independently accredited and regularly audited quality systems.
African Metal Suppliers is largest manufacturers & exporters of super duplex uns s32760 Pipe. we are supplying super duplex uns s32760 Pipe in South Sudan, Namibia , Botswana, Ghana, Uganda, Nigeria, Ethiopia, Zimbabwe , Kenya , Angola, Lesotho, Democratic Republic of The Congo, South Sudan,Rwanda, South America, Liberia, Mozambique, Mauritius.African Metal Suppliers supplies S32760, super duplex stainless steel S32750 OR Duplex 2507. Most of these grades are available in the form of plate, sheet, pipe, tubing, fittings, bar, flanges, wire and rod.
we are also manufacturers, suppliers, exporters and stockists of Inconel Products, Incoloy Products , Monel Products, Hastelloy Products, Nickel Alloy Products, Stainless Steel Products, Duplex Stainless Steel Products, Super Duplex Stainless Steel Products in the form of Pipe, Tube, Sheet & Plate, Pipe Fittings,Olets, Flanges, Fasteners, Wire & Rods.
African Metal Suppliersspecializes in super duplex uns s32760 Pipe .With years of experience in manufacturing super duplex uns s32760 Pipe we offer high quality, lower cost but the best service.Our goal is to fulfill the highest expectations of our customers for delivery and product quality of super duplex uns s32760 Pipe.Our super duplex uns s32760 Pipe is available in a variety of shapes and sizes to meet your project’s needs.African Metal Suppliers Supply super duplex uns s32760 Pipe for application in various spheres of the industries ranging from basic industries such as Sugar, Paper, Textile, Dairy, Engineering to more complex such as Oil & Gas, Petrochemical, Chemical & Fertilizers, Power Generation and Nuclear Industries.
 |
General Information of super duplex uns s32760 Pipe ?
Super Duplex Alloy UNS S32760 (F55 / 1.4501) has excellent corrosion resistance to a wide variety of media, with outstanding resistance to pitting and crevice corrosion in seawater and other chloride containing environments, with Critical Pitting Temperature exceeding 50°C.Providing higher strength than both austenitic and 22% Cr Duples Stainless Steels UNS S32760 (F55) is suited to a variety of applications in industries such as Chemical Processing, Oil & Gas, and Marine environments.
UNS S32760 (F55 / 1.4501) is listed in NACE MR 01 75 for sour service and having gained ASME Approval for Pressure Vessel applications. Our stock of Super Duplex 32760 can be supplied in sheet, plate, or bar forms, cut to specific requirements and comes with the white metals quality certification.
African Metal Suppliers supplies S32760, super duplex Stainless Steel S32750 OR Duplex 2507. Most of these grades are available in the form of plate, sheet, pipe, tubing, fittings, bar, flanges, wire and rod.
super duplex uns s32760 Pipe Production Range
| Range |
15 NB UP TO 600 NB IN SCH 5S , 10S ,10, 20 , 40S , 40 , STD , 60 , 80S , 80 , XS , 100 , 120 , 140 , 160 & XXS
|
| Form | Seamless / ERW / Welded in Round & Square |
| Length | Single Random, Double Random & Cut length |
| Standard | ASTM / ASME SB 163 / 167 / 517 / 704 / 705 |
| Grade | S32760, super duplex Stainless Steel S32750 OR Duplex 2507 |
| Super Duplex Stainless Steel | ASTM / ASME SA 790 UNS NO S 31803 , S 32205 , S 32550 , S 32750 , S 32760 |
| Export To: | South Sudan, Namibia , Botswana, Ghana, Uganda, Nigeria, Ethiopia, Zimbabwe , Kenya , Angola, Lesotho, Democratic Republic of The Congo, South Sudan, Rwanda, Zambia, Liberia, Mozambique, Mauritius |
African Metal Suppliers continues to expand its manufacturing facilities and product ranges to meet the current and future demands of the capital equipment industries.
- Large diameter (up to 100″) / heavy wall welded pipes (up to 60mm)
- Unit length up to 12 mtrs with no circular joints
- Pipes produced by plate, welded and calibrated, ID/OD tight tolerances
- Stainless / Duplex / Super Duplex/Ni alloys
- Production capacity up to 15.000 tons per year
- Advanced welding techniques
- Mill approved by Shell, Total, Aramco, PDO, Exxon, Statoil and others
super duplex uns s32760 Pipe Composition
Specification
| Alloy | Common Name | Related Specifications | Tensile Strength | Proof Stress | Elongation | ||
|---|---|---|---|---|---|---|---|
| British | European | United States | |||||
| Super Duplex
UNS S32760 |
Zeron 100 | 1.4501 | UNS S32760 | F55 | 750 [109] | 550 [79.8] | 25 |
Chemical Composition super duplex uns s32760 Pipe
| C | Si | Mn | Cr | Mo | Ni | W | Cu | N | PREN |
|---|---|---|---|---|---|---|---|---|---|
| 0.020 | 0.25 | 0.55 | 25.20 | 3.70 | 7.00 | 0.65 | 0.60 | 0.22 | Min. 40 |
Mechanical Properties super duplex uns s32760 Pipe
Condition: quenched
| Product | Dimension
Size mm |
0.2% proof stress
N/mm2 min. |
Tensile strength
N/mm2 min. |
Elongation A5
% min. L Q T |
Impact strength
(ISO-V) J min. L Q T |
|---|---|---|---|---|---|
| St, Sch | ≤250 | 550 | 750 | 25 - – - - | 70 - – - - |
| Bl | ≤ 75 | - – 251) - - | - - 55 - - |
St = Bar , Sch = Forging,
Bl = Sheet or plate
L = Longitudinal, Q = Transverse, T = Tangential
1) < 3mm = A80mm specimen
The values for other products and dimensions shall be established by
agreement.
Physical Properties super duplex uns s32760 Pipe
Condition: quenched
| 0.2% yield strength
N/mm² min. |
Temperature | |||||
|---|---|---|---|---|---|---|
| 50°C (122°F) | 100°C (212°F) | 150°C (302°F) | 200°C (392°F) | 250°C (482°F) | 300°C (572°F) | |
| 510 | 480 | 445 | 405 | 400 | 395 | |
Type Of super duplex uns s32760 Pipe
- super duplex uns s32760 Seamless Pipe
- super duplex uns s32760 Welded Pipe
- super duplex uns s32760 SAW Pipe
- super duplex uns s32760 Seamless Tube
- super duplex uns s32760 Welded Tube
- super duplex uns s32760 Pipe
- super duplex uns s32760 Tube
Available super duplex Stainless Steel Grade
super duplex uns s32760 Pipe Cost
- Duplex stainless 2507seamless steel pipe
US $4500-6000 / Ton ( FOB Price) - super duplex stainless steel pipe
US $1000-2000 / Ton ( FOB Price) - super duplex Stainless Steel Seamless Tube & Pipe
US $6500-8500 / Ton ( FOB Price) - super duplex stainless steel welded pipe
US $1000-2000 / Ton ( FOB Price) - super duplex stainless steel welded tube
US $4500-6000 / Ton ( FOB Price) - super duplex stainless steel saw pipe
US $1000-2000 / Ton ( FOB Price) - super duplex stainless steel tube
US $6500-8500 / Ton ( FOB Price) - super duplex Stainless Steel S32760
US $10-20 / Kilogram ( FOB Price)
super duplex uns s32760 Pipe Application
- Desalination Equipment
- Chemical process pressure vessels, piping and heat exchangers
- Marine Applications
- Flue Gas Scrubbing Equipment
- Pulp & Paper Mill Equipment
- Offshore Oil production/technology
- Oil and gas industry equipment
super duplex uns s32760 Pipe Marking & Packing
Lot of emphasis is placed on the packing and packaging . The super duplex uns s32760 Pipe are packed in wooden corrugated boxes foiled in plastic wraps and bubble wraps. Caps / Bushing are made available to the ends on request of the buyer. All super duplex uns s32760 pipe are offered with a NACE 3.1 Certification, Mill Test Certification and ISO 17025 Standards by a Government of Africa approved Laboratory. Positive Material Identification is done on all raw material procured at African Metal Suppliers
Supply Area :
We Supply Our super duplex uns s32760 Pipe to various countries like South Sudan, Namibia , Botswana, Ghana, Uganda, Nigeria, Ethiopia, Zimbabwe , Kenya , Angola, Lesotho, Democratic Republic of The Congo, South Sudan, Rwanda, Zambia, Liberia, Mozambique, Mauritius etc.
super duplex uns s32760 Pipe Ready Stock
super duplex uns s32760 Pipe Application Industries
African Metal Suppliers Supply super duplex uns s32760 Pipe for application in various spheres of the industries ranging from basic industries such as
- Oil & Gas Industry
- Refineries Industry
- Petrochemical Industry
- Fertilizers Industry
- Aerospace Industry
- Nuclear Power Plant Industry
- Chemical Industry
- Paper Industry
African Metal Suppliers is largest manufacturers & exporters of super duplex uns s32760 Pipe. we are supplying super duplex uns s32760 Pipe in South Sudan, Namibia , Botswana, Ghana, Uganda, Nigeria, Ethiopia, Zimbabwe , Kenya , Angola, Lesotho, Democratic Republic of The Congo, South Sudan, Rwanda, Zambia, Liberia, Mozambique, Mauritius. we are also manufacturers, suppliers, exporters and stockists of Inconel Products, Incoloy Products , Monel Products, Hastelloy Products, Nickel Alloy Products, Stainless Steel Products, Duplex Stainless Steel Products, Super Duplex Stainless Steel Products in the form of Pipe, Tube, Sheet & Plate, Pipe Fittings,Olets, Flanges, Fasteners, Wire & Rods.
